Fly Ash Rubber Hose

When it comes to fly ash rubber hoses, Sandhya Flex stands out as a trusted brand, Provides high-quality fly ash rubber hose with a low investment.

Sandhya Flex fly ash rubber hose is known as light duty, with a working pressure of 7 to 10 bars.

Use: Only suitable for siloed and ready-mix concrete (RMC) industries.

Avoid using it in cement industries.

Application:

Fly Ash Rubber Hose, tank, truck, Bulker loading / unloading or in-plant transfer of dry bulk, sand, lime, slurry etc., suction or discharge of abrasive materials.

Construction:

Lining : Uniform seamless tube of natural and synthetic blend rubber compound with excellent resistance to abrasion.

Reinforcement : Reinforcement of rubber impregnated woven textile applied on bias at approx.45 degree angle combination with galvanized steel wire

Cover : Corrugated/plain cloth marked outer cover made from natural rubber compound with excellent weather and abrasion resistant.

End Connections : Each Hose Length has soft ends for clamping or can be supplied with different type of nipples, flanges or fittings as per requirement.

Cover: W.P. of 1.0 Mpa & Min. B.P. of 3.0Mpa.

W.P. of 1.5 Mpa & Min. B.P. of 4.5Mpa .

Construction of Sandhya Flex Fly Ash Rubber Hose

• Lining abrasion resistance Rubber
• Reinforcement for sustainable for pressure and give the life of rubber Hose
• Helical Wire 12SWG ,10 SWG
  Sustainable for Vacuum and give the flexibility
• Middle/ Filler Rubber
• Cover weather and abrasion resistance Rubber

Construction :

Core: Black colour, Synthetic and natural rubber blend resistant to abrasion

Reinforcement: High Tensile Synthetic Textile cord

Cover: Black colour, Synthetic rubber resistant to ozone, weather and abrasion

Application: For Plaster / Sand placement in construction industry

• Working Pressure: 10 Bar (10Kg/cm2)
• Proof Pressure: 1.5 times of W.P.
• Bursting Pressure: 3 times of W.P.
• Reinforcement: 2 or 3 galvanized wire helices embedded in layers of Rubber compounds
• End Connection: Built –in- Flange Type
• Maxim length: 15 Mtr till 5” Dia
• Application: Suction & Discharge of Sand and Gravel, Mud Slurry, Concrete Slurry / Mining Particles etc.
• Bore: Smooth Bore
• Bending Radius: 10xInner Diameter of Hose
• Vacuum: Minimum 700mmHg (0.9Bar)
• Lining material: NR/SBR Resistant to the passage of Abrasive and Corrosive Products Hardness-50 to 60 Shore A.
• Carcass: Synthetic Textile Plies with Embedded Steel Helix
• Coating Material: Resistance to Severe and Bad Weather
• Temperature: 1° C to 100° C

Sandhya Flex Fly Ash Rubber Hose

Size and length

• 3" (75mm) ID
• 4" (100mm)ID
• 5" (125mm)ID
• 6"(150mm),ID

MS Flanges used in Sandhya Flex Fly Ash Rubber Hose

• As per ASA 150#
• As per Table D
• As per Table E

Known as fixed flanges and swivel flanges/rotating flanges

Length of Sandhya Flex Fly Ash Rubber Hose

• 3mtr
• 4mtr
• 5 mtr
• 6 mtr
• And max 20mtr
